Water Tank
Water Tank For Solar Heating Systems
(1). It adopts the no welding line with the blue diamond
internal bladder, and the lifespan is especially long.
(2). For the all closed separated tank, the rated pressure
is 0.6Mpa.
| |
| |
|
Place of Origin |
China |
Model Number |
Pressurized Tank |
|
Price Terms |
FOB, CIF |
Brand Name |
HG& OEM |
|
Payment Terms |
T/T, L/C |
Minimum Order |
1 sets |
|
Supply Ability |
2,500sets/month |
Delivery Time |
7 days | |
| |
|
|
| |
|
Model |
100L |
150L |
200L |
250 |
300L |
|
Rated pressure |
0.6 MPa |
0.6 MPa |
0.6 MPa |
0.6 MPa |
0.6 MPa |
|
Working pressure |
0.55 MPa |
0.55 MPa |
0.55 MPa |
0.55 MPa |
0.55 MPa |
|
Rated
power |
1.5KW |
1.5KW |
1.5KW |
1.5KW |
1.5KW |
|
Temp.
Control |
30-75℃ |
30-75℃ |
30-75℃ |
30-75℃ |
30-75℃ |
|
Qty per 20’/40’ container |
90/194 |
63/134 |
53/114 |
44/94 |
38/81 | |
| |
| |
- Points for Attention
For your safe, please make sure pay attention to following items:
Forbid putting through the power if the water is not full in the tank, otherwise the tank will be damaged.
You have choice for using the AC 220V~/50Hz or the AC 110V~/60Hz
The ammeter, electric wire, the socket that connected with the separated tank must meet the demand of specified electric current of separated tank.
The plug and socket of the separated tank must be connected firmly.
In cold areas, if you don’t use the water heater for a long time in winter, please keep the bladder empty, in case the water inside will be frozen and damage the tank.
When heated, please don't close the cold-water stop valve, in order to lengthen the lifespan of the tank.
It is suggest that operate the temperature / the operation pole of the pressure relief valve by hand frequently, in order to avoid the relief valve and the valve seat carding being blocked and cause danger.
When use the separated tank, if the enactment temperature is higher than 60℃,you must make the cold water and hot water mixed, so as not to scald, especially to the elder and children. |
| |
|
|
|
|
|
Diagram of electric appliance schematic |
|
| | |
- Usage
(1). Water supply:
First, open the close valve of the outlet of the tank and one hot faucet, and keep the water pipeline open. When the hot faucet works normally, which means water is full and then you could close the faucet.
(2). Settlement of hot water temperature:
The temperature regulation range of the temperature controller of the tank is 30~75℃, and the set temperature at 65℃ before dispatched from the factory.
Warning: Please pay attention to the scalding dangerous of the hot water, especially for the children and elders.
(3). Inserting the plug:
There must be good earth and three feet when you use the plug, and make the socket and power dry. The electric current that the outlet and wire allow passing is more than the one of the nominal current of the water heater.
(4). Using of hot water:
After heating to the established temperature, the power showing light will be put out, and then the water heater will be the state of keeping warm automatically. At this time, you can use the hot water, and obtain the suitable temperature by mixed regulating with the cold faucet. The cold water in the water heater willsupplement automatically while using the hot water, at the same time the temperature controller will set up an electric circuit to heat automatically. If you don’t use the water in the short time.
Please don’t close the power of the tank because its good performance of keeping warm doesn’t waste too much electricity.
(5). Close the water heater:
Close the power first, and then close the hot water globe valve of the water heater.
Warning: Forbid regarding the debugger on the safety plug as the switch, we must pull out the safe plug.
- Maintain
(1). Remove the dirt:
In order to make sure the tank work normally and efficiently, you should keep maintain regularly, and remove the dirt from the water. If you use the one-way safety drainage valve，please cut off the electric source, close the water inlet valve, open the outlet valve, and operate the drainage handle.(See the picture) to drain the dirt. After this procedure is finished, make sure that the tank is full of water, then put the current though.
(2). Change the magnesium bar
Propose to check the magnesium bar once after installation and using the water heater for two years; you must change it if the magnesium bar is run out.
- Trouble Shooting
(1) No water comes out
A. Check the tap water to see whether the water supply is cut off or not, or the water pressure
is too low.
B. Whether close valve of the water supply tube is open
C. Whether each interface is blocked or not.
(2) The water temperature is too low:
A. Check the setting temperature if it is too low, or maybe the specification of the water heater
you choose can’t meet your need. So you must choose the specification according to the
actual consumption.
B. Check the regulation proportion of the mixture –water valve if it is normal.
(3) Temperature/ Pressure relief valve is leaked:
A. Working normally: It is the normal phenomenon that there’s a little water, which discharge
when heated.
B. Leaking continually:
Try to lift the temperature / pressure relief operating pole upwards gently for several seconds,
which can dispel some small impurity and fix the breakdown, and then slack off the operating
pole.
C. Pouring water continually for long time:
It states the pressure of the running water is higher than the one of the regulated pressure
of the water heater sometimes. Please ask the installing worker to fix a limited pressure valve.
Warning: Forbid to replace the original safety valve with a higher set pressure safety valve. | |
